Preface

Attention: the newest version of dcm2bids changed the way they write their config files…

⚠️ Breaking changes alert ⚠️
dcm2bids>=3.0.0 is not compatible with config files made for v2.1.9 and below. In order to develop dcm2bids new features we had to rewrite some of its code.
Since v3.0.0, dcm2bids has become more powerful and more flexible while reducing the burden of creating config files. Porting your config file should be relatively easy by following the How-to upgrade page. If you have any issues with it don’t hesitate to report it on Neurostars.

Be sure to check out the dcm2bids website for info about the new conventions: https://unfmontreal.github.io/Dcm2Bids/dev/upgrade/#changes-to-existing-description-and-config-file-keys

Intro

Brain Imaging Data Structure, or BIDS for short, is an effort to standardize the way researchers store their data. BIDS provides a common, consistent directory hierarchy and naming system for files, as well as supporting ‘sidecar’ files for key associated data (like stimulus timing information for task fMRI). With a fixed standard for representing data, this has supported the creation of a number of ‘BIDS apps’, self-contained programs that can automatically process data arranged according to BIDS.

Resources

Main website: https://bids.neuroimaging.io/
Here is a great introductory resource: Getting started with BIDS
Dr. Alexander Weber gave a journal club presentation you can check out here: https://drive.google.com/file/d/1PLNlKTI0xGlbKmIgfwzR8j6nv9RlmxOa/preview

File organization

Part of BIDS is making sure all files are located and named in a standardized format. Generally it should look something like this:

project/
└── subject
    └── session
        └── datatype

More specifically:

myProject/
└── sub-01
    └── ses-01
        └── anat

Here's an example:

ds001
├── dataset_description.json
├── participants.tsv
├── sub-01
│   ├── anat
│   │   ├── sub-01_inplaneT2.nii.gz
│   │   └── sub-01_T1w.nii.gz
│   └── func
│       ├── sub-01_task-balloonanalogrisktask_run-01_bold.nii.gz
│       ├── sub-01_task-balloonanalogrisktask_run-01_events.tsv
│       ├── sub-01_task-balloonanalogrisktask_run-02_bold.nii.gz
│       ├── sub-01_task-balloonanalogrisktask_run-02_events.tsv
│       ├── sub-01_task-balloonanalogrisktask_run-03_bold.nii.gz
│       └── sub-01_task-balloonanalogrisktask_run-03_events.tsv
├── sub-02
│   ├── anat
│   │   ├── sub-02_inplaneT2.nii.gz
│   │   └── sub-02_T1w.nii.gz
│   └── func
│       ├── sub-02_task-balloonanalogrisktask_run-01_bold.nii.gz
│       ├── sub-02_task-balloonanalogrisktask_run-01_events.tsv
│       ├── sub-02_task-balloonanalogrisktask_run-02_bold.nii.gz
│       ├── sub-02_task-balloonanalogrisktask_run-02_events.tsv
│       ├── sub-02_task-balloonanalogrisktask_run-03_bold.nii.gz
│       └── sub-02_task-balloonanalogrisktask_run-03_events.tsv
...
...
└── task-balloonanalogrisktask_bold.json

Tutorial

As always, Andy’s Brain Book has a tutorial where you can download data and follow along: https://andysbrainbook.readthedocs.io/en/latest/OpenScience/OS/BIDS_Overview.html

Examples

https://github.com/bids-standard/bids-examples

This repository contains a set of BIDS-compatible datasets with empty raw data files. These datasets can be useful to:

write lightweight software tests

serve as an example on how a BIDS dataset can be structured

`dcm2bids`

One of the nicest ways to convert your raw .dcm files to NIfTI AND organize into BIDS structure is to use a command line program called dcm2bids

What dcm2bids does:

Reads your raw DICOMs.
Uses dcm2niix under the hood to convert images to NIfTI format (commonly used in neuroimaging).
Renames and organizes them into the correct BIDS directory structure (e.g., sub-01/anat/sub-01_T1w.nii.gz, sub-01/func/sub-01_task-rest_bold.nii.gz).
Adds JSON sidecar files with acquisition metadata.
Can be customized with a configuration file (.json) to map your scanner sequence names to BIDS-compatible names.

Info and Tutorials

Please take a look at the documentation to:

Another tutorial

Install

Dependencies: you will need dcm2niix installed first though

pip install dcm2bids

Upgrading

pip install --upgrade dcm2bids

Example Walkthrough

1. Create a root BIDS directory

Create and enter your root BIDS directory where everything will live:

cd /your/projects/folder/for/example/ && mkdir 2020-09-17_BCCHR_test_AlexW/
cd 2020-09-17_BCCHR_test_AlexW/

2. Create the basic architecture of your directory

dcm2bids_scaffold

This gives us several generics folders and files.
One of the created folders is named 'sourcedata/'

data from Xnat is downloaded as a zip into 'sourcedata/'

then:

cd sourcedata
unzip aweber-20200918_110552.zip

which extracts the dicoms into a folder: aweber-20200918_110552/

inside of which are numbered subfolders for each acquisition scan

going back to /your/projects/folder/for/example/2020-09-17_BCCHR_test_AlexW/

cd ..

3. Use the helper function to get a sense of what NIfTI files and `json` sidecar files you are working with

dcm2bids_helper -d sourcedata/aweber-20200918_110552/

This command will convert the DICOMs files to NIfTI files and save them inside 'tmp_dcm2bids/helper/'

[note: with GE data, I find this gives bad naming conventions. Alternatively you could run something like this:

dcm2niix -o tmp_dcm2bids/helper -b y -ba y -z y -f ‘%3s %f %d %r’ sourcedata/AMW01/

which translates to:
-o = output folder [note: this folder should already exist]
-b y = BIDS sidecar yes
-ba y = anonymize BIDS yes
-z y = gz compress images yes
-f '%3s %f %d %r' = filename with series number, folder name,
description and instance number]

We should see a list of compressed NIfTI files (nii.gz) with their respective sidecar files (.json).
For this example, we will imagine we only have three acquisitions:

003_LONGMBfMRI_SAG_FSPGR_3D\_.9X.9X.9_20200917132212.json\
003_LONGMBfMRI_SAG_FSPGR_3D\_.9X.9X.9_20200917132212.nii.gz\
005_LONGMBfMRI_fMRI_Resting_State_AP_20200917132212.json\
005_LONGMBfMRI_fMRI_Resting_State_AP_20200917132212.nii.gz\
006_LONGMBfMRI_fMRI_Resting_State_PA_20200917132212.json\
006_LONGMBfMRI_fMRI_Resting_State_PA_20200917132212.nii.gz

4. Build your configuration file with the help of the content of

`tmp_dcm2bids/helper`:

Now we will create a configuration file called dcm2bids_config.json (this is just an example, it could be whatever we want) in the code/ folder.
Use any text editor to create the file with the contents:

{
    "descriptions": [
        {
        "datatype": "anat",
        "suffix": "T1w",
        "criteria": {
            "SeriesDescription": "SAG_FSPGR_3D_.9X.9X.9*"
            }
        },
        {
        "datatype": "func",
        "suffix": "bold",
        "custom_entities": "task-rest-AP",
        "criteria": {
            "SeriesDescription": "fMRI_Resting_State_AP*"
            }
        },
        {
        "datatype": "func",
        "suffix": "bold",
        "custom_entities": "task-rest-PA",
        "criteria": {
            "SeriesDescription": "fMRI_Resting_State_PA*"
            }
        }
    ]
}

5. Run `dcm2bids`

Now we are ready to run dcm2bids with our config file:

dcm2bids -d sourcedata/aweber-20200918_110552/LONGMBfMRI \
  -p 01 -c code/dcm2bids_config.json

where: -d is the sourcedirectory; -p is the subject ID; and -c is the config file.

A bunch of information is printed to the terminal and we can verify that the data are now in BIDS.

ls sub-01/*

sub-01/anat:\
sub-01_T1w.json sub-01_T1w.nii.gz

sub-01/func:\
sub-01_task-rest_bold.json sub-01_task-rest_bold.nii.gz

dcm2bids creates log files inside /your/projects/folder/for/example/tmp_dcm2bids/log

7. Validate

Run the bids-validator to check your directory.

This needs to be installed separately; or you can use the web interface and upload your data.

See Section 9

Tip

Don't forget to create a .bidsignore file at the root of your BIDS directory with tmp_dcm2bids/* inside.

echo tmp_dcm2bids >> .bidsignore

Config Examples:

1. Example config file:

https://unfmontreal.github.io/Dcm2Bids/dev/how-to/create-config-file/

{
  "descriptions": [
    {
      "datatype": "anat",
      "suffix": "T2w",
      "criteria": {
        "SeriesDescription": "*T2*",
        "EchoTime": 0.1
      },
      "sidecar_changes": {
        "ProtocolName": "T2"
      }
    },
    {
      "id": "task_rest",
      "datatype": "func",
      "suffix": "bold",
      "custom_entities": "task-rest",
      "criteria": {
        "ProtocolName": "func_task-*",
        "ImageType": ["ORIG*", "PRIMARY", "M", "MB", "ND", "MOSAIC"]
      }
    },
    {
      "datatype": "fmap",
      "suffix": "fmap",
      "criteria": {
        "ProtocolName": "*field_mapping*"
      },
      "sidecar_changes": {
        "IntendedFor": "task_rest"
      }
    },
    {
      "id": "id_task_learning",
      "datatype": "func",
      "suffix": "bold",
      "custom_entities": "task-learning",
      "criteria": {
        "SeriesDescription": "bold_task-learning"
      },
      "sidecar_changes": {
        "TaskName": "learning"
      }
    },
    {
      "datatype": "fmap",
      "suffix": "epi",
      "criteria": {
        "SeriesDescription": "fmap_task-learning"
      },
      "sidecar_changes": {
        "TaskName": "learning",
        "IntendedFor": "id_task_learning"
      }
    }
  ]
}

Where:

“datatype” is the folder the file will be stored under. Can be:
- func (task based and resting state functional MRI)
- dwi (diffusion weighted imaging)
- fmap (field inhomogeneity mapping data such as field maps)
- anat (structural imaging such as T1, T2, PD, and so on)
- perf (perfusion)
- meg (magnetoencephalography)
- eeg (electroencephalography)
- ieeg (intracranial electroencephalography)
- beh (behavioral)
- pet (positron emission tomography)
- micr (microscopy)
- nirs (near infrared spectroscopy)
- motion (motion)
- mrs (magnetic resonance spectroscopy)
- phenotype (measurement and survey data)
“suffix” is literally what will be written at the end of the file. Common examples: T1w, T2w, epi, bold, dwi…
“criteria” is what will be searched in the sidecar json file to identify your file.
“id” this is literally an id you give this to use later when you need to refer to this scan. An example is when you need to set an “IntendedFor” for the fmap to point to the right func
“custom_entities” is useful for things like fMRI, when you will want identify if it is rest, or listening, or motor, etc.
“sidecare_changes” is when you are not happy with the json sidecar that is automatically made, and you need to add some information
“B0FieldIdentifier” tells us what kind of correction you intend: e.g. “pepolar_fmap0”

So, the above example has:

a T2w scan, that will be stored in the anat folder
an fMRI scan that will be stored in the func folder; has been given an ‘id’ for later when we need to associate fmaps to it; what kind of task it is (rest)
an field map scan to be used with the rest task: “IntendedFor”
another fMRI scan that will be stored in the func folder; has been given a different ‘id’ for later when we need to associate fmaps to it; what kind of task it is (rest)
another field map to be used to correct the learning task

2. Another example

Another example for T1w, resting-state fMRI, and two short blip-up / blip-down spin-echo sequences for field-map estimation:

{
  "dcm2niixOptions": "-b y -ba y -z y -f '%3s_%f_%d_%r'",
  "descriptions": [
    {
      "datatype": "anat",
      "suffix": "T1w",
      "criteria": {
        "SeriesDescription": "SAG_FSPGR_3D_.9X.9X.9"
      }
    },
    {
      "id": "task-rest",
      "datatype": "func",
      "suffix": "bold",
      "custom_entities": "task-rest",
      "criteria": {
        "SeriesDescription": "RestStatefMRI_HB4PA1"
      },
      "sidecar_changes": {
        "TaskName": "rest"
      }
    },
    {
      "datatype": "fmap",
      "suffix": "epi",
      "custom_entities": "dir-AP",
      "criteria": {
        "SeriesDescription": "SE_fMRI_pepolar_0",
        "PhaseEncodingPolarityGE": "Unflipped"
      },
      "sidecar_changes": {
        "IntendedFor": [
          "task-rest"
        ],
        "B0FieldIdentifier": "pepolar_fmap0"
      }
    },
    {
      "datatype": "fmap",
      "suffix": "epi",
      "custom_entities": "dir-PA",
      "criteria": {
        "SeriesDescription": "SE_fMRI_pepolar_1",
        "PhaseEncodingPolarityGE": "Flipped"
      },
      "sidecar_changes": {
        "IntendedFor": [
          "task-rest"
        ],
        "B0FieldIdentifier": "pepolar_fmap0"
      }
    }
  ]
}

“dcm2niixOptions”: “-b y -ba y -z y -f ‘%3s_%f_%d_%r’”,

This tells dcm2bids how to run dcm2niix. I found this created more helpful filenames when running dcm2bids_helper

Note

Currently dcm2bids will create json files for the fmaps that have an “IntendedFor”” field that fmriprep will not correctly know what to do with:

"IntendedFor": "bids::sub-AHIE001/func/sub-AHIE001_task-rest_dir-AP_bold.nii.gz",

You will need to rewrite this for now to say:

"IntendedFor": "func/sub-AHIE001_task-rest_dir-AP_bold.nii.gz",

You will notice that both the bids:: and the sub-AHIE001 has been removed.

fmriprep plans to eventually fix this: https://neurostars.org/t/dcm2bids-version-3-1-0-intended-for-field/27888/4

Not super helpful to anybody right now, but the next release will have experimental support for BIDS-URIs. (January 2024)

Automate BIDS

Here is a tutorial on how to create a bash shell script to automate this process
https://reproducibility.stanford.edu/bids-tutorial-series-part-1b/

Better `json` writing

`jo`

jo is a simple program that makes writing json files easier (I think)
https://github.com/jpmens/jo

Example:

jo -p descriptions=$(jo -a $(jo datatype=anat suffix=T1w criteria=$(jo SeriesDescription=SAG_FSPGR_3D_.9X_.9X.9*)) $(jo datatype=func suffix=bold custom_entities=task-rest-AP criteria=$(jo SeriesDescription=fMRI_Resting_State_AP*)))

Results in:

{
   "descriptions": [
      {
         "datatype": "anat",
         "suffix": "T1w",
         "criteria": {
            "SeriesDescription": "SAG_FSPGR_3D_.9X_.9X.9*"
         }
      },
      {
         "datatype": "func",
         "suffix": "bold",
         "custom_entities": "task-rest-AP",
         "criteria": {
            "SeriesDescription": "fMRI_Resting_State_AP*"
         }
      }
   ]
}

Validator

You can test whether your data is in BIDS format using this link and uploading the main folder

Or you can install a program on the computer you are using:
bids-validator

Install

sudo apt-get install nodejs
sudo apt-get install npm
sudo npm install -g bids-validator

Run

bids-validator .

Or, if you're using docker:

docker run -ti --rm -v /your/projects/folder/for/example:/data:ro bids/validator /data

but change /your/projects/folder/for/example to where your BIDS files are.

If you are in the directory already, then '.' is your current directory.

Important

Don't forget to create a .bidsignore file at the root of your BIDS directory with tmp_dcm2bids/* inside.

source, rawdata, derivatives

If you are unclear how you can organize your BIDS dataset (named rawdata) in relation the data that it was built from (named sourcedata) and in relation to the preprocessed that came from it (named derivatives) maybe the example figure below can help.

BIDS Example: converting .PAR/REC files to BIDS

In a new "BIDS" folder, run

dcm2bids_scaffold

copy data into the "sourcedata" folder it created

cp -a /data* BIDS/sourcedata

dcm2bids_helper -d sourcedata

to convert files to NIfTI (the nifti and json files are in tmp_dcm2bids)

write config file in code folder

Example:

nano dcm2bids_config.json

{
    "descriptions": [
        {
        "datatype": "anat",
        "suffix": "T1w",
        "criteria": {
            "SidecarFilename": "003*"
            }
        },

        {
         "datatype": "func",
         "suffix": "bold",
         "custom_entities": "task-rest_run-01",
         "criteria": {
            "SidecarFilename": "006*"
        },
        "sidecar_changes": {
            "TaskName": "rest"
        }
      }
    ]
}

write conversion script in parent folder (BIDS) of sourcedata. This file should specify the subject (-p) and session (-s) that corresponds to the data in sourcedata.

Example:

nano bids_format.sh

dcm2bids -d sourcedata/MINT_01_001/baseline/ -p 01 -s 01 -c code/dcm2bids_config.json
dcm2bids -d sourcedata/MINT_01_001/completion/ -p 01 -s 02 -c code/dcm2bids_config.json
dcm2bids -d sourcedata/MINT_01_002/baseline/ -p 02 -s 01 -c code/dcm2bids_config.json
dcm2bids -d sourcedata/MINT_01_002/completion/ -p 02 -s 02 -c code/dcm2bids_config.json
dcm2bids -d sourcedata/MINT_01_M137/MINT_01_SCREEN52/baseline/ -p 37 -s 01 -c code/dcm2bids_config.json
. . .
dcm2bids -d sourcedata/MINT_01_M137/completion/ -p 37 -s 02 -c code/dcm2bids_config.json
dcm2bids -d sourcedata/MINT_01_M138/baseline/ -p 38 -s 01 -c code/dcm2bids_config.json
dcm2bids -d sourcedata/MINT_01_M138/completion/ -p 38 -s 02 -c code/dcm2bids_config.json

Run bids_format.sh with

./bids_format.sh

Run bids validator

docker run -ti --rm -v /mnt/WeberLab/Projects/Alzheimer_Nygaard/bids_all_subjects/:/data:ro bids/validator /data

To get rid of some of the errors, you may need to:

make a file named .bidsignore and have files that you want to tell bids to ignore: tmp_dcm2bids, bids_format.sh
delete "funding" line from dataset_description.json
add a line of text to README file

Run fmriprep from bids_all_subjects. See the fmriprep page for details

fmriprep-docker . derivatives/ participant --fs-license-file /usr/local/freesurfer/license.txt

Preface

Intro

Resources

File organization

Tutorial

Examples

dcm2bids

Info and Tutorials

Install

Upgrading

Example Walkthrough

1. Create a root BIDS directory

2. Create the basic architecture of your directory

3. Use the helper function to get a sense of what NIfTI files and json sidecar files you are working with

4. Build your configuration file with the help of the content of

5. Run dcm2bids

7. Validate

Config Examples:

1. Example config file:

2. Another example

Automate BIDS

Better json writing

jo

Validator

Install

Run

source, rawdata, derivatives

BIDS Example: converting .PAR/REC files to BIDS

`dcm2bids`

3. Use the helper function to get a sense of what NIfTI files and `json` sidecar files you are working with

5. Run `dcm2bids`

Better `json` writing

`jo`
